M10 Male Rod End Bearing POS10 — 2 Pack Heavy-Duty Rose Joints, RH Thread

Heavy-duty M10 male rod end bearings (POS10) for high-load motorsport, industrial and heavy machinery applications. Also known as rose joints, spherical bearings or heim joints. Supplied as a pair with 10mm bore and right-hand thread.

Key Specifications

• Model: POS10 (male thread, positive series)
• Thread: M10 × 1.5 right-hand
• Bore diameter: 10mm
• Construction: Zinc plated steel body
• Bearing type: Self-lubricating spherical
• Angular range: ±13° typical
• Load rating: Up to ~1,500kg static

Perfect For

• Heavy-duty motorsport suspension links
• Custom kit-car and race car builds
• Industrial hydraulic actuator mounts
• Agricultural machinery pivot joints
• Trailer and load-carrying linkages
• Adjustable panhard rods and tie bars

Installation Tips

• Always use lock nuts to prevent loosening under vibration and load cycles
• Don't over-tighten the pivot pin — the 10mm bore must move freely
• Fit into an M10 female thread with proper thread-locker for high-vibration applications
• For adjustable rods, pair with a female PHS10 rod end and jam nut

Frequently Asked Questions

What's the difference between POS and PHS? POS is male (threaded stud outward). PHS is female (threaded hole inward). See our full guide: Rod End Bearing Guide.

What's the max load for M10? ~1,500kg static, ~750kg dynamic (moving load) is a safe working limit.

Are they suitable for racing use? Yes — routinely used in club-level motorsport suspension. For professional race use, inspect after every event.

Can I use them for adjustable suspension? Absolutely — pair with a PHS10 female rod end for length-adjustable links.

Fast UK Dispatch

Orders placed Monday to Sunday before 16:00 are dispatched same-day from UK stock via Royal Mail, Yodel, UPS or DPD.

Explore More

See our full Rod End Bearings collection — M6, M8, M10 in both male (POS) and female (PHS) versions.
